Storeroom

Sheet metal - privacy protection (FP)

3D

A storage area can reveal a great deal. Or nothing at all. We at Axelent can meet all storeroom requirements. Our FP system supplied not with mesh but with solid walls, is developed for spaces with high safety and stability requirements but where what is in the storeroom does not need to be monit...

Få dit tilbud nu

Modeller

Downloads

Storeroom, sheet metal

Monteringsvejledning

Safe-X | Storerooms

Brochure

Safe-X | Storeroom Technical information

Produktinformation

Tekniske specifikationer

A storage area can reveal a great deal. Or nothing at all. We at Axelent can meet all storeroom requirements. Our FP system supplied not with mesh but with solid walls, is developed for spaces with high safety and stability requirements but where what is in the storeroom does not need to be monitored.



  • Extra strong tubular door design.
  • Can be combined with F, FK and FK+ systems.
  • Can be cut and adapted to existing building dimensions.
  • Can be fitted with ceiling at heights above 3.2 metres.
  • The walls are painted in sendzimir, the doors in colour RAL 9018.
Product facts
Product Size (mm) Description
Steel wall, profiled sheet 30 Depth of profiling
Steel wall, profiled sheet 0,7 Sheet thickness
Vertical tubes 40x20 Tubular steel frame, door
Horizontal tubes 35x15 Tubular steel frame, door
50-7090 1870x860 Door opening dimensions
